ALOGIC MA3 USB-C Triple Display Docking Station
ALOGIC MA3 Overview
Turn your notebook into a full-fledged workstation with the robust connectivity of the ALOGIC MA3 USB-C Triple Display Docking Station. Designed for business users, you can easily scale your desktop depending on your needs, giving you multiple displays, peripheral support, and more.
Equipped with two DisplayPort and one HDMI outputs, you can support two or three display configurations with 4K resolution as well as 60 and 30 Hz refresh rate, respectively. You get two USB-A 2.0 ports for low-powered devices such as mice and keyboards while two USB-A 3.2 Gen 1 give you up to 5 Gb/s data transfer speeds and support for resource-demanding peripherals. A USB-C port on the back connects to your system and offers up to 100W Power Delivery, charging your system while in use. Two front-facing USB-C 3.2 Gen 2 ports give you up to 10 Gb/s data transfer speeds and one of these offer Fast Charging capabilities so you can recharge your mobile device quickly. You also get an SD card reader so you can quickly move files from your camera to your PC. A single 3.5mm audio jack provides you with headset support, allowing you to take part in various conference calls or listen to your media privately. A single Gigabit Ethernet port allows you to use a wired connection to your network for a strong and reliable connection. Additionally, a built-in lock slot allows you to use various security devices to prevent theft.
In the Box
- ALOGIC MA3 USB-C Triple Display Docking Station
- 170W AC Power Adapter & Power Cord
- Limited 2-Year Manufacturer Warranty
ALOGIC MA3 Specs
| USB |
2 x USB-C 3.1/3.2 Gen 2
2 x USB-A 3.0 / 3.1/3.2 Gen 1 2 x USB-A 2.0 |
| Ethernet |
1 x RJ45 (10/100/1000 Mb/s)
|
| Display |
2 x DisplayPort 1.4
1 x HDMI 2.0 |
| Audio |
1 x 1/8" / 3.5 mm Headphone/Microphone Combo Jack
|
| Media Card Reader |
1 x SD (Unspecified Type)
|
| Host Connection |
USB-C (Unspecified Interface)
|
| USB |
2 x USB-C 3.1/3.2 Gen 2
2 x USB-A 3.0 / 3.1/3.2 Gen 1 2 x USB-A 2.0 |
| Ethernet |
1 x RJ45 (10/100/1000 Mb/s)
|
| Display |
2 x DisplayPort 1.4
1 x HDMI 2.0 |
| Audio |
1 x 1/8" / 3.5 mm Headphone/Microphone Combo Jack
|
| Media Card Reader |
1 x SD (Unspecified Type)
|
| Host Connection |
USB-C (Unspecified Interface)
|
| Connection Type |
Detachable Cable
|
| Powered Connection |
100 W
|
| Number of Displays Supported |
3
|
| Maximum Resolution Supported |
3840 x 2160 at 60 Hz (Dual Display)
3840 x 2160 at 30 Hz (Triple Display) |
| HDCP Support |
No
|
| OS Compatibility |
Windows
*As of February, 2023: Check with manufacturer for the most up-to-date compatibility |
| UASP Support |
No
|
| Power Source |
AC Adapter
|
| Power I/O |
Barrel Connector (Unspecified Diameter)
|
| Maximum Power Consumption |
170 W
|
| Certifications |
FCC, CE, RoHS
|
| Color |
Black
|
| LED Indicator |
No
|
| Enclosure Material |
ABS
|
| Lock Slot |
No
|
| Weight |
12.7Ā oz / 360Ā g
|
| Package Weight |
3.795 lb
|
| Box Dimensions (LxWxH) |
10.8 x 6 x 3.5"
|
All product and company names are trademarksā¢ or registeredĀ® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
