American DJ UV LED BAR20 IR Backlight with UC IR Remote Control
American DJ UV LED BAR20 IR Overview
Lighting designers and event coordinators in need of a bright UV wash light will be inspired by the American DJ UV LED BAR20 IR, a high output ultraviolet LED backlight, well suited for performance stages, theatrical productions, and special effects installations. The UV LED BAR20 comes with the UC IR wireless remote for easy control of on/off and strobe speed.
The fixture is powered by twenty 1W UV LEDs and includes a beam with an angle of 10° vertical and 40° horizontal. With an LED life of approximately 50,000 hours, the UV LE 20 IR is suitable for washing stages, nightclubs, bowling centers, roller rinks, and fun centers with ultraviolet light. Users can control the fixture from the built-in 3-button LCD menu, DMX control, included UC IR wireless remote, or the Airstream IR app.
- Bright, high-output Ultraviolet Bar with 20 x 1-watt UV LED
- Includes UC IR wireless remote control (control on/off and strobe speed)
- Great for performance stages, theatrical productions and special effects installations�requires almost no maintenance�long life LED, low heat output, low power consumption and no moving parts
- Long life LEDs (50,000 hours)
- Low-power consumption, low heat
- 4 operational modes: Sound Active, DMX512, Primary/Secondary, or Manual
- 3 DMX channel modes: 1, 2, or 3 channels
- UV strobe effect
- Electronic Dimming: 0 to 100%
- Flicker free
- Refresh Rate: 1 kHz
- Beam angle: 10° vertical x 40° horizontal linear beam angle�great for wall washing
- Linkable via 3-pin XLR cable
- 3-button LED DMX display on rear panel
- Locking power connections in/out to daisy-chain power (10 fixtures at 120V; 20 fixtures at 230V)
- Scissor yoke allows fixture to be hung or set on the ground
- Airstream IR APP compatible with iOS device
Items Included
- American DJ UV LED BAR20 IR Backlight with UC IR Remote Control
- UC IR Wireless Remote Control
- Power Cord
- Limited 2-Year Manufacturer Warranty
Additional Resources
American DJ UV LED BAR20 IR Specs
| Fixture Type |
Linear/Bar Light
|
| Light Source |
20x Ultraviolet LED - 1 W
|
| Colors |
Ultraviolet
|
| UV Wavelength |
390 to 410 nm
|
| Control Protocols |
DMX512
|
| AC Input Power |
100 to 240 VAC, 50/60 Hz
|
| Power / Current Consumption |
30 W
|
| Mounting |
Dual/Scissor Yoke
|
| Fixture Type |
Linear/Bar Light
|
| Light Source |
20x Ultraviolet LED - 1 W
|
| Expected Lamp Life |
50,000 Hours
|
| Colors |
Ultraviolet
|
| UV Wavelength |
390 to 410 nm
|
| Coverage Angle |
10 x 40°
|
| Shutter / Strobe |
Electronic
|
| Dimming |
Electronic, 0 to 100%
|
| Operating Modes |
DMX, Primary/Secondary, Sound-Active, Standalone
|
| Macros / Programs |
No
|
| Effects |
Strobe
|
| Gobos |
No
|
| Refresh Rate |
1 kHz
|
| Control Protocols |
DMX512
|
| DMX Channel Modes |
3 Mode(s):
1 / 2 / 3-Channel |
| Display / Controls |
LED / 3-Button
|
| Remote Control |
IR Remote (with Included Equipment)
|
| Mobile App Compatible |
No
|
| Inputs/Outputs |
1 x XLR 3-Pin DMX Input/Output
|
| Wireless |
IR
|
| AC Input Power |
100 to 240 VAC, 50/60 Hz
|
| AC Power Connector |
Input: 1x powerCON
Output: 1x powerCON |
| Power / Current Consumption |
30 W
|
| Power Linking |
10 Units at 120 VAC
20 Units at 230 VAC |
| Environmental Resistance |
No
|
| Mounting |
Dual/Scissor Yoke
|
| Included Accessories |
1x Power Cable
1x Controller |
| Duty Cycle |
No
|
| Exterior Color |
Black
|
| Dimensions |
13.25 x 2.5 x 7" / 33.66 x 6.3 x 17.8 cm
|
| Weight |
5 lb / 2.3 kg
|
| Package Weight |
6.65 lb
|
| Box Dimensions (LxWxH) |
17.95 x 9.05 x 4.75"
|
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
