Belden 9841 060100 Multipair Cable Computer Screened 1 Pair 24 AWG 0.205 mm² 100 ft 30.5 m
The 9841 060100 is a 100ft 1-pair low capacitance Computer Cable with 24AWG stranded (7 x 32) tinned copper conductors, polyethylene insulation, overall Beldfoil® aluminium foil-polyester tape (100% coverage) + tinned copper braid shield (90% coverage) and chrome PVC jacket. Belden multi-conductor cable deliver low voltage analog data and signal transmission within enclosures from controllers and I/O's to devices such as temperature and pressure sensors, relays, valves, meters, thermocouples, solenoids, actuators, contactors, push buttons and alarms. This computer cable is designed for EIA RS-485 applications.
- CPR: Eca
- 120R Impedance
- 12.8pF/ft Conductor to conductor nominal capacitance
- 23pF/ft Conductor to other conductor and shield nominal capacitance
- 24R/1000ft at 20°C Nominal conductor DC resistance
- 3.4R/1000ft at 20°C Nominal outer shield DC resistance
- UL1685 Flame tested
Computers & Computer Peripherals
Product details
| Cable Shielding | Screened |
| No. of Pairs | 1 Pair |
| Wire Gauge | 24AWG |
| Conductor Area CSA | 0.205mm² |
| Reel Length (Imperial) | 100ft |
| Reel Length (Metric) | 30.5m |
| Jacket Colour | Chrome |
| No. of Max Strands x Strand Size | 7 x 0.2mm |
| Voltage Rating | 300V |
| Jacket Material | PVC |
| Conductor Material | Tinned Copper |
| External Diameter | 5.89mm |
| Product Range | - |
Other details
| Brand | BELDEN |
| Part Number | 9841 060100 |
| Quantity | Reel of 30 |
| Technical Data Sheet EN |  |
