Bourns SRU1048-470Y Power Inductor (SMD) 47 µH 1.7 A Shielded 1.5 SRU1048 Series 10mm x 4.8mm

The SRU1048 series SMD shielded Power Inductor with ferrite DR and RI core. It has silver/nickel/tin termination and an enamelled copper wire winding. It is suitable for input/output of DC/DC converters.

• Available in E6 series
• Unit height of 4.8mm
• -40 to 125°C Operating temperature range

Applications

Power Management, Industrial, Portable Devices, Communications & Networking, Consumer Electronics, Automotive

Product details

Inductance	47µH
RMS Current (Irms)	1.7A
Inductor Construction	Shielded
Saturation Current (Isat)	1.5A
Product Range	SRU1048 Series
Power Inductor Case	10mm x 10mm x 4.8mm
DC Resistance Max	0.094ohm
Inductance Tolerance	± 30%
RoHS Phthalates Compliant	To Be Advised

Other details

Brand	BOURNS
Part Number	SRU1048-470Y
Quantity	Each (Supplied on Cut Tape)
Technical Data Sheet EN
3D Product Image EN
