Bridgelux BXRC-30G4000-C-73 LED Warm White 90 CRI Rating 41W 4000lm 1.17A 120° 35V 3000K Round With Flat Top
Vero represents a revolutionary advancement in chip on board (COB) light source technology and innovation. Vero LED light sources simplify luminaire design and manufacturing processes, improve light quality, and define a platform for future functionality integration. Vero is available in four different light emitting surface (LES) configurations and has been engineered to reliably operate over a broad current range, enabling new degrees of flexibility in luminaire design optimization. Vero arrays deliver increased lumen density to enable improved beam control and precision lighting with 2 and 3 SDCM color control standard for clean and consistent uniform lighting.
- Efficacy of 155 lm/W typical
- Vero 18 lumen output performance ranges from 2044 to 13232 lumens
- Broad range of CCT options from 2700K to 5000K
- CRI options include minimum 70, 80, and 90, 2 and 3 SDCM color control for 2700K-4000K CCT
- Reliable operation at up to 2X nominal drive current
- Radial die pattern and improved lumen density
- Thermally isolated solder pads
- Onboard connector port
- Top side part number markings
LED Lighting
Product details
| COB Colour | Warm White |
| Color Rendering Index Max | 90 |
| Power Rating | 41W |
| Luminous Flux @ Test | 4000lm |
| Forward Current @ Test | 1.17A |
| Viewing Angle | 120Ā° |
| Forward Voltage VF Typ | 35V |
| Nominal CCT (K) | 3000K |
| COB Length | - |
| COB Width | - |
| Opto Case Style | - |
| Lumens / Watt @ Current Test | 127lm/W |
| Light Emitting Surface | 18.4mm |
| Lens Type | - |
| Lens Shape | Round with Flat Top |
| Height | 1.9mm |
| Product Range | Gen 7 Vero 18 Array Series |
| RoHS Phthalates Compliant | To Be Advised |
Other details
| Brand | BRIDGELUX |
| Part Number | BXRC-30G4000-C-73 |
| Quantity | Each |
| Technical Data Sheet EN |  |
All product and company names are trademarksā¢ or registeredĀ® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
