IMO Precision Controls SRRHN-2CN-SL-12VDC SRRHN-2CN-SL-12VDC General Purpose Relay Srrhn Series Power Non Latching Dpdt 12 VDC 8 A
The SRRHN-2CN-SL-12VDC is a Miniature High Power Relay with DC coil. This SRRHN-series power relay has 2CO (DPDT) silver nickel contacts with solder through hole terminals. Class-B insulation. 5KV dielectric coil to contacts.
- Sealed construction
- 10mm Creepage distance
- 2000VA Maximum switching power
- 15ms Operate and 8ms release maximum time
- -40 to 85ĆĀ°C Ambient temperature range
- IP67 Protection rating
- Flux-tight protection
Industrial
Warnings Market demand for this product has caused an extension in leadtimes. Delivery dates may fluctuate. Product exempt from discounts.Other details
| Brand | IMO PRECISION CONTROLS |
| Part Number | SRRHN-2CN-SL-12VDC |
| Quantity | Each |
| Technical Data Sheet EN |  |
