SAMTEC FTS-105-01-L-D Board-To-Board Connector, 1.27 mm, 10 Contacts, Header, FTS Series, Through Hole, 2 Rows
The FTS series from Samtec are 1.27mm pitch micro low profile terminal strips.
- Pitch spacing is 1.27mm (2 to 50 contacts per row) with double row through hole mounting (-D)
- High operating temperature range of -55�C to 125�C
- Contact material is phosphor bronze
- Black liquid crystal polymer insulator material
- Current rating is 3.3A
- Complies with UL E111594 standard
- 10�" gold plated contacts
Applications
Industrial
Product details
| No. of Contacts | 10Contacts |
| Contact Plating | Gold Plated Contacts |
| Gender | Header |
| Product Range | FTS Series |
| Contact Material | Phosphor Bronze |
| Contact Termination Type | Through Hole |
| Pitch Spacing | 1.27mm |
| No. of Rows | 2Rows |
Other details
| Brand | SAMTEC |
| Part Number | FTS-105-01-L-D |
| Quantity | Each |
| Technical Data Sheet EN |  |
| Drawing EN | |
| 3D Product Image EN | |
