SCHNEIDER ELECTRIC ABL6TS63U Isolation Transformer, Phaseo Optimum, 630 VA, 1 x 230V, 1 x 400V, 230V, ABL 6TS Series
The Phaseo ABL6TS series from Schneider are safety and isolation single phase transformers. These transformers have input voltage of 230VAC or 400VAC at 50 or 60Hz depending on the model. The Phaseo transformers provide enhanced electrical isolation between the line supply and the application.
- Available in 12VAC, 24VAC, 115VAC and 230VAC output voltage
- Power rating ranges from 25VA to 2500VA
- Operating temperature +60�C
- Panel mounting screw termination
- IP20 degree of protection
Applications
Industrial, Power Management, Safety
Product details
| Plug Type | - |
| Power Rating | 630VA |
| Isolation Transformer Primary Voltages | 1 x 230V, 1 x 400V |
| Current Rating | - |
| Product Range | ABL 6TS Series |
| Secondary Voltages | 230V |
Other details
| Brand | SCHNEIDER ELECTRIC |
| Part Number | ABL6TS63U |
| Quantity | Each |
| Technical Data Sheet EN |  |
| Drawing EN | |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
