Traco Power THN 20-4811WI THN 20-4811WI Isolated Through Hole DC/DC Converter ITE 4:1 20 W 1 Output 5 V 4 A

The THN 20-4811WI is a high performance DC-DC Converter achieves 20W output power. The device features an ultra-wide 4:1 input voltage range while the output voltages are precisely regulated even under no load conditions. It offers 18 to 75VDC input voltage range and 5VDC output voltage. This device allows very reliable and applicable in temperature ranges of up to 85°C. The low no-load input current characteristics and the remote ON/OFF control make this converter an ideal solution for battery operated systems. The converter is suitable for many applications where space on the PCB is critical.

• Shielded metal case with isolated base plate
• Output voltage adjustable
• No minimum load required
• 1500VDC I/O isolation voltage
• 89% Typical efficiency
• 48VDC Nominal input voltage

Applications

Consumer Electronics, Sensing & Instrumentation, Communications & Networking, Power Management

Other details

Brand	TRACO POWER
Part Number	THN 20-4811WI
Quantity	Each
Technical Data Sheet EN
Application Note EN
Miscellaneous EN
CAD Multiple Formats EN
