TRACOPOWER TEN 25-2411WI Isolated Board Mount DC/DC Converter, Fixed, Adjustable, 1 Output, 10 V, 40 V, 25 W, 5 V

This is a Isolated Board Mount DC/DC Converter, Fixed, Adjustable, 1 Output, 10 V, 40 V, 25 W, 5 V product from TRACOPOWER with the model number TEN 25-2411WI

Product details

Output Power Max	25W
Input Voltage DC Min	10V
DC / DC Converter Mounting	Through Hole
Output Voltage - Output 2	-
Output Current - Output 2	-
Depth	50.8mm
Width	40.6mm
Product Range	TEN 25WI Series
DC / DC Converter Type	DIP
Approvals & Standards	IEC, UL
Output Voltage - Output 3	-
Output Voltage - Output 1	5V
Output Current - Output 3	-
No. of Outputs	1 Output
DC / DC Converter Output Type	Fixed, Adjustable
Input Voltage DC Max	40V
Output Current - Output 1	5A
Height	9.3mm

Other details

Brand	TRACOPOWER
Part Number	TEN 25-2411WI
Quantity	Each
Technical Data Sheet EN
