TRACOPOWER TEP 200-2415WIRCMF Isolated Board Mount DC/DC Converter, Medical, 1 Output, 180 W, 24 V, 7.5 A
The TEP 200WIR series isolated high performance DC-DC Converter Module with ultra-wide 4:1 input voltage ranges. It comes in chassis mount version with screw terminal block and with integrated EMI input filter to meet EN 55022 class-A. A very high efficiency allows full power operation at 25�C with only 100LFM air flow cooling and operation at 60�C with only 40% power derating. The very wide input voltage range and reverse input voltage protection makes this converter interesting solution for battery operated systems.
- No minimum load
- Soft-start
- Under voltage lock-out circuit
- Sense line
- Remote ON/OFF input
- Reverse input voltage protection
- Overtemperature protection
- Up to 91% very high efficiency
Applications
Communications & Networking, Automation & Process Control, Power Management, Industrial
Product details
| Output Power Max | 180W |
| Input Voltage DC Min | 8.5V |
| DC / DC Converter Mounting | Chassis |
| Output Voltage - Output 2 | - |
| Output Current - Output 2 | - |
| Depth | 85mm |
| Width | 61mm |
| Product Range | TEP 200WIR Series |
| DC / DC Converter Type | Module |
| Approvals & Standards | IEC, UL |
| Output Voltage - Output 3 | - |
| Output Voltage - Output 1 | 24V |
| Output Current - Output 3 | - |
| No. of Outputs | 1 Output |
| DC / DC Converter Output Type | Fixed, Adjustable |
| Input Voltage DC Max | 36V |
| Output Current - Output 1 | 7.5A |
| Height | 33.8mm |
Other details
| Brand | TRACOPOWER |
| Part Number | TEP 200-2415WIRCMF |
| Quantity | Each |
| Technical Data Sheet EN |  |
