TRACOPOWER TES 1-2423 Isolated Board Mount DC/DC Converter, 2 Output, 1 W, 15 V, 35 mA, -15 V, 35 mA
This is a Isolated Board Mount DC/DC Converter, 2 Output, 1 W, 15 V, 35 mA, -15 V, 35 mA product from TRACOPOWER with the model number TES 1-2423
Product details
| No. of Outputs | 2 Output |
| Output Power Max | 1W |
| Output Voltage - Output 1 | 15V |
| Output Current - Output 1 | 35mA |
| Output Voltage - Output 2 | -15V |
| Output Current - Output 2 | 35mA |
| Output Voltage - Output 3 | - |
| Output Current - Output 3 | - |
| Product Range | - |
| Input Voltage DC Min | 21.6V |
| Input Voltage DC Max | 26.4V |
| DC / DC Converter Output Type | Fixed |
| DC / DC Converter Type | Surface Mount DIP |
| DC / DC Converter Mounting | Surface Mount Device |
| Approvals & Standards | - |
| Width | 8mm |
| Height | 7mm |
| Depth | 16.3mm |
Other details
| Brand | TRACOPOWER |
| Part Number | TES 1-2423 |
| Quantity | Each |
| Technical Data Sheet EN |  |
| Miscellaneous EN | |
| Application Note EN | |
All product and company names are trademarksā¢ or registeredĀ® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
