VISHAY MAL210118223E3 CAP, ALU ELEC, 22000UF, 63V, SCREW

This is a CAP, ALU ELEC, 22000UF, 63V, SCREW product from VISHAY with the model number MAL210118223E3

Product details

Capacitance	22000µF
Voltage Rating	63V
Product Range	101 PHR-ST Series
Lifetime @ Temperature	10000 hours @ 85°C
Capacitance Tolerance	± 20%
Capacitor Terminals	Screw
Diameter	50mm
Lead Spacing	22.2mm
Operating Temperature Min	-40°C
Operating Temperature Max	85°C
Height	80mm
ESR	0.019ohm
Automotive Qualification Standard	-

Other details

Brand	VISHAY
Part Number	MAL210118223E3
Quantity	Each
Technical Data Sheet EN
