American DJ NET 8 DMX Over Ethernet Node (8-Port)
American DJ Net 8 Overview
Experience a new level of dynamic lighting setups with the NET 8 DMX Over Ethernet Node from American DJ. The NET 8 supports all the industry-standard protocols, including Art-Net, sACN, DMX, and RDM to expand your integration possibilities. The eight 5-pin XLR ports can be configured as inputs or outputs. The NET 8's intuitive interface features a 1.7" LCD for onboard adjustments, but control is also possible from a web browser. Highly versatile to suit various applications, power options include traditional AC input or Power over Ethernet (PoE). The unit can be mounted within a 19" rack case.
- Choose between DHCP or static IP address settings
- Two RJ45 input and output
- Eight 5-pin XLR inputs/outputs
- Compact and lightweight design
- CE and FCC certified
- IP20 rated
- Includes locking power cord
Items Included
- American DJ NET 8 DMX Over Ethernet Node (8-Port)
- Locking Power Cord
- Limited 2-Year Manufacturer Warranty
Additional Resources
American DJ Net 8 Specs
| Inputs/Outputs |
2x RJ45 Female Input/Output
8x XLR 5-Pin Female Output 1x (Power) powerCON Input |
| Power Source |
AC Power
|
| Protocol |
ArtNet, DMX512, RDM, sACN
|
| Inputs/Outputs |
2x RJ45 Female Input/Output
8x XLR 5-Pin Female Output 1x (Power) powerCON Input |
| Dimming |
Optional
|
| Power Source |
AC Power
|
| Power Consumption |
5.7 W
|
| Input Power |
95 to 240 VAC, 50 / 60 Hz
|
| PoE Port Power |
Yes
|
| Protocol |
ArtNet, DMX512, RDM, sACN
|
| Operating Temperature |
-4 to 113°F / -20 to 45°C
|
| Operating Humidity |
75%
|
| Storage Temperature |
77°F / 25°C
|
| Certifications |
CE, cETLus, FCC
|
| Environmental Resistance |
Dust-Resistant (IP20)
|
| Dimensions |
19.0 x 5.1 x 1.7" / 482.6 x 129.3 x 43.9 mm
|
| Weight |
4.76 lb / 2.16 kg
|
| Package Weight |
5.845 lb
|
| Box Dimensions (LxWxH) |
23.1 x 8.6 x 3.4"
|
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
